750kw Medium Frequency Induction Heating Power Supply
Equipment Power: 750kw
Oscillation Frequency: 1-5KHZ
Control Components:IGBT
Delivery Time: 3-20 days after confirming order,detail delivery date should be decided according to production season,order quantity and destination.
Warranty: 12 Months
Online Inquiry
-
-
Equipment introduction
750kw Medium Frequency Induction Heating Power Supply
Features of Induction Heating Power Supply:
1)Multi-stage temperature control (Default 5 stages, Customizable).
2)The heating time can be accurate to 0.1S, and the heating current is accurate to 1A.
3)Support parameter storage, which can be recalled on a computer and other equipment with one key.
4)Abundant communication interfaces, which can be connected to industrial buses such as RS-485, profibus, CAN, etc.
5)Multiple operation modes are available, including manual mode, automatic mode, and temperature control mode.
6)Real-time display of processing parameters, drawing of current and frequency curves, more. 7)intelligent Interactive man-machine.
Technical Parameters
Product Name
Medium Frequency Induction Heating Power Supply
Control Mode
Digital
0perating Mode
Manual mode、 automatic mode、 temperature control mode
Number of Heating Current Settings
5-32 segments
Number of Workpiece Parameters Stored
10 group
Work Status
Time、current、frequency、current time curve
Alarm Interface
Lack of water、over current、over voltage、lack of phase.over current of the drive board,abnormal load、out of control，etc
Model
DIH-400
DIH-800
DIH-1200
DIH-1600
Output Power
250KW
500KW
750KW
1000KW
Output Frequency
1一5KHz
Extension Cords Size
3M
Input Voltage
380V士10%
Input Frequency
50/60Hz
Input Power Factor
0.93
Maximum Water Temp of Inlet Water
<35℃
Cooling Water Flow
12.5-17L/min
Chassis Size
1200*800*2300
Application of Induction Heating Power Supply:
1)Metal SmeltingUsed for smelting of copper, aluminum, gold, silver and other non-ferrous metals.
2)Diathermic Forging
Used for diathermy forging of brass, stainless steel and carbon steel.
3)Quenching
Quenching of gears, sprockets, shafts, hardware tools, machine tool guides, and auto parts .
4)Other Uses
Curing bonding, thermal assembly, heat treatment, pre-heating before welding, post-heating, straightening and leveling.
